5.12kw ZT Lithium Battery ZT-51100B

Here are the specifications for the ZT-51100B LiFePO₄ battery:

Physical

• Battery Type: LFP (LiFePO₄)
• Weight: 55 kg
• Dimensions (W × L × H): 600 × 423 × 203 mm
• Protection Level: IP20
• Warranty: 5 years

Electrical Parameters

• Nominal Capacity: 5.12 kWh
• Cell Capacity: 100 Ah
• Depth of Discharge: 90 %
• Rated Voltage Range: 43.2 V – 56 V

Operation

• Rated Charge/Discharge Current: 50 A / 100 A
• Max. Charge/Discharge Current: 100 A
• Rated DC Power: 5.12 kW
• Charge Temperature: 0 °C – 58 °C
• Discharge Temperature: –18 °C – 58 °C
• Humidity Range: 0 % – 90 %
